PureThermal 3
PureThermal 3
If you liked the PureThermal 2, youāll love the PureThermal 3! With a USB-C connector and updated Boot and Reset buttons, you can use this hackable thermal webcam with your FLIR Lepton camera core.
SKU:
Couldn't load pickup availability
PureThermal 3 (PT3) is a hackable thermal webcam for the FLIR Lepton (2.x, 3.x, FS, 3.1R, and UW) LWIR camera cores. It has the same basic functionality of the PureThermal 2 but with a few changes and additional features. Unlike the PT2, the PT3 does not have pads to install an RF shield and the Tag-Connect TC2030 programming connector is replaced by the Tag-Connect EC-10-IDC.
šLead Timeš
If you can add this item to your cart it is in stock and ready to ship
Design, PCB Fabrication, and Assembly Done in the USA!
New Features:
- USB-C connector
- Flash custom firmware with USB DFU
- Castellated edge with full JTAG breakout for rapid flashing
- Works withĀ Tag-Connect EC-10-IDC
- Better buttons for Boot and Reset
- 3x STM32F412CG GPIO pins
- PC15, PA0, PH1
- Breakout for SPI to communicate directly with the Lepton
- SPI bus is 3V with a 56 Ohm series resistor
- PartiallyĀ MikroBUSā¢ compatible breakout pin configuration
- SeeĀ the mikroBUSā¢ standard PDF.
- +5V is V_IN and +3.3V is +3V on PureThermal 3
Features:
- STM32F412 ARM microprocessor: Execute on-board image processing without the need for an external system or SBC.
- USB UVC works on Windows, Linux, Mac, and sometimes Android
- Open source reference firmware is on theĀ GroupGets Github
- Open source referenceĀ image viewer software for Linux and macOS
- USB-C connector
- Flash custom firmware with USB DFU
- Castellated edge with full JTAG breakout for rapid flashing
- Better buttons for Boot and Reset
- 3x STM32F412CG GPIO pins
- PC15, PA0, PH1
- Breakout for SPI to communicate directly with the Lepton
- SPI bus is 3V with a 56 Ohm series resistor
- PartiallyĀ MikroBUSā¢ compatible breakout pin configuration
- SeeĀ the mikroBUSā¢ standard PDF.
- +5V is V_IN and +3.3V is +3V on PureThermal 3
Resources:
Software
- GetThermal for x86 - Linux/macOS (open source)
- GetThermal for Raspberry Pi
- Multi PT1 Frame Grabber (beta, unofficial)
Mechanical:
Weight : <3g without Lepton
Press:
- PureThermal 3 board embeds FLIR Lepton FS thermal camera for $200 - CNX Software
- GroupGets Launches the PureThermal 3, a $200 Hackable FLIR Lepton FS Thermal Camera Board
Export Information
- Part Number: PURETHERMAL-3
- ECCN:Ā EAR99
- HTSUS:Ā 9027.50.4020
- Country of Origin: USA
